3 Ton Electric Forklift
The heavy end of the mainstream electric range and the most widely stocked size in China. A 3-ton electric truck handles dense pallets, container stuffing and heavy industrial work, and it is the size where the electric-versus-diesel decision becomes a genuine cost calculation rather than a preference.
Every layer, and what it is actually made of.
Scroll to separate the machine into its load-bearing layers. Each part carries the material grade, the tolerance that matters, the warranty position and the supply-chain note behind it.
Scroll to expand · drag to rotate · click a part to inspect
Select a part on the diagram to inspect its specification.
- Material
- Key tolerance
- Performance
Material grades, tolerances and warranty positions are shown as typical values for this configuration. They are confirmed in writing per supplier route before you commit — we do not publish a grade we have not verified.
What this configuration means
Values are typical reference ranges. The final specification is confirmed per supplier route against your actual application.
| Rated capacity | 3,000 kg |
|---|---|
| Load centre | 500 mm (confirm per route) |
| Lift height | 3,000–6,000 mm, mast dependent |
| Fork length | 1,220 mm standard |
| Power | Electric, 48 V / 60 V / 80 V class depending on route |
| Battery | Lead-acid or lithium; capacity confirmed per route |
| Charger | Included or optional — confirmed per route |
| Tyre | Solid or pneumatic |
| Typical use | Dense pallets, container loading, heavy industrial handling |
Where this machine is used
- Container loading and unloading
- Heavy palletised goods and dense loads
- Manufacturing and steel-adjacent handling
- Ports, yards and outdoor-indoor transitions
What we need from you
- Load weight, dimensions and load centre
- Lift height and whether container work is involved
- Ground conditions and tyre preference
- Shifts and charging strategy
- Whether the machine ships assembled or knocked down
The options we compare for this machine
We do not publish factory names before you reach quotation stage. If we did, the cheapest quote would get copied within days and stop being real. So each option is shown by region and what stands behind it — names come when you are ready to order.
| Option | Quotes behind it | Made in |
|---|---|---|
| S028 | 20 | Shandong — Jining |
| S027 | 11 | Shandong — Jining |
| S033 | 11 | Hebei — Xingtai |
| S031 | 10 | China |
| S032 | 7 | China |
| S034 | 6 | China |
| S029 | 4 | China |
| S026 | 3 | Shandong — Jining |
| S030 | 3 | Zhejiang — Huzhou |
Straight answers on 3 Ton Electric Forklift
3-ton electric or 3-ton diesel?
Indoor work, emissions rules and two-shift duty favour electric. Long outdoor shifts, poor charging access or very dusty yards still favour diesel. We compare both on your duty cycle and site conditions, not on preference.
Can a 3-ton electric forklift load a container?
Yes, but the mast and overhead clearance decide how. Container stuffing usually needs free lift and a low collapsed mast height. Tell us if container work is part of the job and we will specify for it.
What battery voltage should I choose?
Higher voltage generally means more efficient heavy duty and faster lifting, but it also means a different charger and often a higher price. It is a configuration decision, not a spec sheet number — we match it to your duty.
Related Electric Counterbalance Forklifts
Ready to check this machine for your site?
Send the load, lift height, battery strategy and destination port — we will confirm the configuration and compare routes.
